Connex (CX-33HP-MAX) - AM/FM/PA, Black
Description:
The Connex CX-33HP-MAX features 150+ watt power output,
blue lighting, front mic jack, echo with dual controls
and switchable talkback.
Connex - Amateur and CB Radios
Features and Specifications:
- 10 Meter Mobile Amateur Radio
- AM/FM/PA
- 150+ Watts
- Small Meter with Scales for Signal Strength and Power
Output
- Front Panel 4 Pin Mic Jack
- Blue Channel LED's
- Rear Frequency Counter Jack
- Three Position Dimmer Control
- Vol, Sql, Mic Gain, RF Gain
- Dual Echo and Talk Back with On/Off/+10KHz Switch
- Band Selector (6 Bands)
- 2 Level Power Control
- ANL-NB or RB-NB-ANL or OFF Switch
- Blue Lighting for Meter
- RX/TX Indicator LED
- Specifications:
- General:
- Model: CX-33HP-MAX
- Frequency Range: 28.015 to 28.585 MHz
- Emission: AM/FM
- Frequency Control: Phase-Lock-Loop (PLL)
Synthesizer
- Frequency Stability: 0.001%
- Temperature Range: -30C to +50C
- Antenna Impedance: 50 Ohms
- Antenna Connectors: Standard SO-239 type
- Input Voltage: 13.8V DC
- Current Draw: 7 Amp
- Fuse Size: 10 Amp
- Size: 2-3/8" (H) x 7-7/8" (W) x
9-1/4" (D)
- Weight: 4 lb. 3oz.
- Meter: Illuminated; indicates relative output
power, received signal strength
- Transmitter:
- RF Power Output: Hi: 80W; Lo: 5W; Peak AM
150W
- Spurious Emission: > -50 dB
- Audio Distortion: 10%
- Frequency Response: 300 to 2500 Hz
- Microphone: Plug-in dynamic; with
push-to-talk switch and coiled cord
- Receiver:
- Sensitivity for 10 dB (S+N)/N: AM: <1 uV
- Sensitivity for 20 dB (S+N)/N: FM: <1 uV
- Squelch Sensitivity: <0.5 uV
- Sensitivity: >-60dB
- Image Rejection: > 50 dB
- Hum & Noise: >-40 dB
- AGC Figure of Merit: 70 dB for 50 mV for 10
dB Change in Audio Output
- Audio Power Output: 2.5W @ 10% Distortion
- Audio Response: 300 to 2500 Hz
- Contents:
- 10 Meter Connex CX-33HP-MAX Radio
- 4 Pin Stock Microphone
- DC Power Cord
- Mounting Bracket with Hardware
- Microphone Hanger with Hardware
- User's Manual
- UPC 0705105789392
- Color: Black
- Manufacturer's Limited Warranty - 1 Year(s)
- Sold: Each
Connex (CX-33HP-MAX) - AM/FM/PA
Please Note:
- This Selection Is Connex (CX-33HP-MAX) ONLY.
- Manufacturer's product specifications,
packaging and limited warranties (if applicable) are
subject to change.
- Images are solely for illustrative purposes and may
reflect multiple items or multiple views of a single
item.
- This Item Is Sold: Each
