Ranger (RCI-39VHP) - AM/PA, Black with Chrome Face

Description:

The Ranger RCI-39VHP will fit those tight overhead compartments in big trucks designed for a Cobra 29/Galaxy DX 929.

The Ranger RCI-39VHP features 60+ watt power output, blue channel LED, meter which monitors signal strength, RF output power and SWR level, front mic jack, echo with dual controls, variable talkback, 3 position dimmer, variable output power, 6 bands, a 10KHz switch, and a Channel 19 switch.

Ranger Communications, Inc. - Home of top quality communications equipment.

Features and Specifications:

• 10 Meter Mobile Amateur Radio
• AM/PA
• 100 watts
• Dual Control Echo & Adjustable Talkback
• Meter Monitors Signal Strength, RF Output Power & SWR Level
• SWR Circuit that Automatically Calibrates Itself
• RF Noise Blanker and Automatic Noise Limiter
• +10KHz Switch
• Will Act as a Public Address Amplifier in PA Mode
• 3 Position Dimmer Control
• Channel 19 Switch
• Fully Chromed Face
• Variable RF Power Output
• Blue LED Display
• Heat Sink
• Ranger Chrome and Black SRA-198C Noise Canceling Microphone
• Specifications:
  • General:
    • Model: RCI-39VHP
    • Frequency Range: 28.765 - 29.205 MHz
    • Emission: AM/PA
    • Frequency Control: Phase-Lock-Loop (PLL) Synthesizer
    • Frequency Stability: 0.001%
    • Temperature Range: 25C
    • Antenna Impedance: 50 Ohm
    • Input Voltage: 13.8V DC Normal @ 10 AMP
    • Size: 11.03" (L) x 7.29" (W) x 2.37 (H)
    • Size: 28cm (L) x 18.5cm (W) x 6.0 (H)
    • Weight: 3.97 Lbs.
    • Weight: 1.8KG
    • Meter: RF Output, RX Receive Signal Strength, SWR
  • Transmitter:
    • RF Power Output: AM: 60W PEP
    • Antenna Connectors: Standard SO-239 type, 50 Ohms
    • Spurious Emission: > -65 dB
    • Audio Distortion: < 10%
    • Frequency Response: 300 to 2500 Hz
    • Microphone: Plug-in (4-Pin) dynamic; with push-to-talk switch and coiled cord
  • Receiver:
    • Sensitivity: AM: 0.5 uV for 10dB S+N/N
    • Squelch Sensitivity: < 0.5 uV
    • Image Rejection: > 50 dB
    • Audio Power Output: 3W @ 10% THD
    • Audio Response: 300 to 2500 Hz
• Contents:
  • 10 Meter RCI-39VHP Radio
  • 4 Pin Chrome & Black Ranger SRA-198C Noise Cancelling Mic
  • DC Power Cord
  • Mounting Bracket with Hardware
  • User's Manual
• Color: Black with Chrome Face
• Manufacturer's Limited Warranty - 1 Year(s)
• Sold: Each

Ranger RCI-39VHP - 10 Meter Amateur Radio

Ranger RCI-39VHP - Operation's Guide

The RCI-39VHP User's Manual
