Kenwood (KDC-BT958HD) - CD Receiver with Built-in
Bluetooth & HD Radio, SiriusXM Ready, 3 Line/2 Line
Selectable Full Dot LCD Display, Variable Color
Illumination, Drive EQ, Dual USB Ports, Pandora
Description:
CD Receiver
KDC-BT958HD
CD Receiver with Built-in Bluetooth & HD Radio
- TDF(Theft Deterrent Faceplate)
- Anti-Dust Flip-up door
- Built-in HD Radio
- Front AUX & Dual USB Interface (Front/Rear)
- Sound Excellence DSP (DTA, Sound Elevation, Highway
Sound... )
- Bluetooth Built-in (Hands-Free Profile / Audio
Profile)
- MP3/WMA/AAC/WAV Files Playback with ID-3 Tag Display
- 3-Line Full Dot LCD
- Variable Color Illumination
- 3 Preouts 4.0V
- Steering Remote-In
- Drive EQ, Pandora, SiriusXM, aha
Overview
Drive EQ
Road noise is the enemy of all audio systems found in
vehicles. The inherent frequencies of road noise masks a
wide range of the audio signal found in music, and this
is the reason KENWOOD engineers developed Drive EQ. Drive
EQ boosts specific frequencies in the audio signal to
compensate the negative impact of road noise.
3 Line/ 2 Line Selectable LCD Display
Choose between a larger two line display or more
information from a three line display.
Dual USB Ports
USB devices can be connected not only to the front panel,
but also to a cable on the rear.
CD Door / Cover
For dust prevention, a CD Door/Cover has also been
adopted.
Works with Pandora Internet Radio for iPhone or
Android
Customized internet radio that plays music based on your
favorite artists. KENWOOD receivers provide a rich
Pandora experience.
Kenwood "Music Control" for Android
smartphone
Download this free application from Google Play and use
the search function to easily find a track you would like
to listen by using the artist name or the
like.*Compatible only with Android smartphones supporting
mass storage devices.
SiriusXM Ready
SiriusXM is channels and channels of anything you want to
listen to. Commercial-free music, sports, talk radio and
entertainment. If that's not enough there is comedy,
news, traffic, weather and more. It can all be found on
SiriusXM.
iHeartRadio for iPhone and Android
iHeart Radio is an Internet radio platform that delivers
content from over 800 local Clear Channel radio stations
from all over the United States. iHeart also functions as
a music recommendation system, making it easy and fun to
discover new music.
HD Radio
HD Radio has improved FM and AM sound quality, more
content with the additional broadcast channels.
Variable Color Illumination
You can select a preset color or create your own to match
the dashboard lighting or your mood of the day.
Play music via Audio Streaming (A2DP/AVRCP)
Easily stream music from your phone or other Bluetooth
devices directly to thereceiver. Functions such as track
name display and track search are also available from the
receiver.
Voice Dialing / Siri Eyes Free
The receiver will allow the voice dialing feature found
on most smartphones to work through Bluetooth.
New External Bluetooth Microphone
For easy installation, a new microphone with angle and
swivel adjustment is included.
Hands Free, Phonebook Transfer
Access Phonebook, Last Calls, and Missed Calls from the
receiver and make hands-free calls.
iPhone Automatic Pairing
Automatic Bluetooth pairing function for iPhone via USB
is available on all built-in Bluetooth receivers.
Kenwood - Live Connected. Drive Connected.
Features and Specifications:
- CD Receiver with Built-in Bluetooth & HD Radio
- General Features:
- TDF(Theft Deterrent Faceplate)
- CD Door / Cover
- 3 Line Full Dot LCD Display
- Rotary Encoder and Direct Key (TEL) for easy
operation
- Music Search & Mixed Preset memory function
- Digital Clock (12H)
- Variable Color Illumination
- Auto Dimmer Control Function (on/off)
- Audio Features:
- Maximum Output Power : 50W x 4 (MOSFET Power IC)
- Front AUX & Dual USB Interface (Front/Rear)
- 3 Preout (4V)
- Supreme sound reconstruction, restores musical to
compressed music
- Sound Excellence DSP:
-
- Digital Time Alignment & Sound Management
System
- Highway sound
- 7 Band Graphical EQ and System Q
- iPod EQ select mode
- Drive EQ
- Supreme
- Space Enhancer
- Sound Realizer
- Sound Elevation
- Loudness
- Bass Boost
- Subwoofer Level Adjustable
- USB Features:
- MP3, WMA, AAC, WAV Decoder with ID-3 Tag Display
- iPod/iPhone Direct Connection with Optional cable
- iPod Alphabet/Skip/2 Speed Search Function
- Pandora / aha Radio App Ready (iPhone App)
- TuneIn / Deezer / Aupeo! Support (iPhone App)
- Compatible with KENWOOD Music Control for Android
- Drive Change (For Android or Card Reader)
- Tuner Features:
- Built-in HD Radio
- Sirius XM Ready
- iTunes Tagging (HD Radio / Sirius XM)
- Backup Memory for Tuner Preset
- FM/AM 24 Station Presets (18FM, 6AM)
- RBDS with Radio Text
- AME (Automatic Memory Entry)
- Up/Down Seek Tuning
- CD Features:
- MP3, WMA, AAC Decoder with ID-3 Tag Display
- Folder Name Manual Search Function without
Stopping Audio-play
- 0-bit Mute
- CD Text Ready
- CD-R/CD-RW Compatible
- Random/Repeat Play
- External Media Control Features:
- Bluetooth Built-in (Hands-Free Profile / Audio
Profile)
- Pandora / aha Radio App Ready (Android App :
A2DP/SPP/Multi Profile)
- OEM Remote Interface
- Rear Wired BT Microphone included
- Specs:
-
- FM Frequency Range (Frequency Step): 87.9MHz
- 107.9MHz (200kHz)
- FM Channel Space Selection: 50k/200kHz
- FM Usable Sensitivity S/N:30dB: 9.3dBf
(0.8microV/75 Ohm)
- FM Quieting Sensitivity S/N 46dB: 10.2dBf
(1.13microV/75 Ohm)
- FM Frequency Response (+/-3.0dB): 30Hz-15kHz
- FM S/N: 75dB(MONO)
- FM Stereo Separation: 45dB(1kHz)
- Digital FM Frequency Range (Frequency Step):
87.9MHz - 107.9MHz (200kHz)
- Digital FM Channel Space Selection:
50k/200kHz
- Digital FM Frequency Response (+/-3.0dB):
20Hz-20kHz
- Digital FM S/N: 75dB(STEREO)
- AM Frequency Range (Frequency Step): 530kHz -
1700kHz (10kHz)
- AM Channel Space Selection: 9k/10kHz
- AM Usable Sensitivity S/N:20dB: 28dBu
(25microV)
- Digital AM Frequency Range (Frequency Step):
530kHz - 1700kHz (10kHz)
- Digital AM Channel Space Selection: 9k/10kHz
- Digital AM Frequency Response(+/-3.0dB):
40Hz-15kHz
- Digital AM S/N: 70dB(STEREO)
- CD Laser Diode: GaAlAs
- CD Digital Filter(D/A): 8 Times OverSampling
- CD D/A Converter: 24 Bit
- CD Spindle Speed (Audio Files): 500rpm -
200rpm(CLV)
- CD Wow & Flutter: Below Mesurable Limit
- CD Frequency Response: 10-20kHz(+/-1dB)
- CD Total Harmonic Distortion: 0.010%(1kHz)
- CD S/N Ratio (dB): 105dB(1kHz)
- CD Dynamic Range: 93dB
- CD MP3 Decode: Compliant with MPEG-1/2 Audio
Layer-3
- CD WMA Decode: Compliant with WINDOWS MEDIA
AUDIO
- CD AAC Decode: AAC-LC ".m4a" files
- USB I/F USB: USB1.1 / 2.0(Full speed)
- USB I/F File System: FAT 12 / 16 / 32
- USB I/F Maximum Supply current: DC5V(DC logo)
1A
- USB I/F decode: MP3/WMA/AAC/WAV Decode
- Preout Level(mV)/Load-Unbalanced: 4000mV/10k
Ohm(CD)
- Preout Impedance(Ohm): <=600 Ohm
- Speaker Impedance(Ohm): 4-8 Ohm
-
- AUX Input Frequency Response: 20 - 20KHz
+/-3dB
- AUX Input Input Maximum Voltage: 1200mV
- AUX Input Input Impedance: 10K Ohm
- AMP Maximum Power: 50wx4
- AMP Full Bandwidth Power (at less than
1%THD): 22wx4
- Bluetooth Version: Bluetooth Ver. 2.1+EDR
Certified
- Bluetooth Frequency Range: 2.402 GHz - 2.480
GHz
- Bluetooth Output Power: +4 dBm (MAX), 0 dBm
(AVE) Power Class 2
- Bluetooth Maximaum Communication Range: Line
of sight approx. 10m (32.8 ft)
- Bluetooth Profile: HFP (Hands Free Profile),
SPP (Serial Port Profile), OPP (Object Push
Profile), PBAP (Phonebook Access Profile),
OPP(Object Push Profile), A2DP(Advanced Audio
Distribution Profile), AVRCP(Audio/Video Remote
Control Profile)
- Tone Bass: -
- Tone Middle: -
- Tone Treble: -
- Tone Band 1: 62.5Hz +/-9dB
- Tone Band 2: 160Hz +/-9dB
- Tone Band 3: 400Hz +/-9dB
- Tone Band 4: 1kHz +/-9dB
- Tone Band 5: 2.5kHz +/-9dB
- Tone Band 6: 6.3kHz +/-9dB
- Tone Band 7: 16kHz +/-9dB
- General Operating voltage (10.5v - 16v
allowable): 14.4v
- General Maximum Current Consumption: 10A
- General Operational Temperature Range: 0C to
+40C
- General Installation Size: 182(mm) 7-3/16(in)
x 53(mm) 2-1/16(in) x 159(mm) 6-1/4(in)
- General Weight: 1.3(kg) 2.9(lbs)
- UPC 0019048206541
- Color: Black
- Sold: Each
Kenwood (KDC-BT958HD) - CD Receiver with Built-in
Bluetooth & HD Radio
Please Note:
- This Selection Is For Kenwood (KDC-BT958HD) ONLY.
- Manufacturer's product specifications,
packaging and limited warranties (if applicable) are
subject to change.
- Images are solely for illustrative purposes and may
reflect multiple items or multiple views of a single
item.
- This Item Is Sold: Each
