JL Audio (PWM110-JXWXv2) - Single 10WXv2 PowerWedge MAX with JX250/1 Amplifier, Sealed, 4 Ohm

Description:

Powered Subwoofer System with Single 10WXv2-4 Subwoofer Driver, Dark Gray Carpet (175 W, 4 Ohm) - Sealed Enclosure

PowerWedge MAX subwoofer systems combine JL Audio's rugged, great-sounding JL Audio WXv2 Subwoofer Drivers with a precisely engineered, USA-built enclosure and a perfectly matched JL Audio JX amplifier.

The JX amplifier is mounted to the PowerWedge Max behind a sleek amplifier shroud with a durable black textured finish. The subwoofer enclosure features durable, automotive-grade carpeting and premium JL Audio speaker wiring.

The angled-back design of the PowerWedge MAX saves precious cargo space by allowing the enclosure to fit tightly against the back of a vehicle's rear seat.

The PowerWedge MAX subwoofer system is shipped wired, loaded and ready to install. If you desire subwoofer level control from the front of the vehicle, add the RBC-1 Remote Bass Control (sold separately).

Finish: Dark gray high-grade automotive carpet.

Construction: CNC-Cut High-Grade MDF

Recommended amplifier power: Built-in JX250/1 (175 W @ 4 Ohm)
Nominal Impedance: 4 Ohm

Enclosure Made in USA

Technology:

PowerWedge MAX

These complete powered solutions deliver amazing value!

PowerWedge MAX Systems combine a perfectly optimized, rear-firing sealed enclosure with a 10-inch or 12-inch WXv2 subwoofer driver and a powerful JL Audio JX Monoblock Subwoofer Amplifier. A great-looking trim panel surrounds the amplifier on the angled back wall of the enclosure.

Ready to rock, right out of the box!

V-Groove MDF Construction - This advanced cabinet-building technique uses CNC-machining to create precise panel joints that make enclosure assembly more efficient and exact.

JL Audio begins with quality medium-density fiberboard, which is then machined on their CNC-controlled KOMO woodworking stations. These powerful machines are able to cut a wide range of features onto a sheet of MDF, with minimal waste and absolute precision. The KOMO machines cut out the woofer holes, terminal holes, cut dado grooves, create countersinks and most importantly, cut the angles at the edges of the panels that form the enclosure's main shell so that these panels fit together precisely, with no gaps or leaks.

Once the panels are cut, assembly technicians line them up in the correct order and glue their outer faces onto a long piece of carpet, creating a "wrap": a long series of panels, hinged temporarily by the carpet. In the next assembly step, JL Audio's wood assembly teams fill the V-grooves between the panels and any dado grooves that receive dividers or secondary wraps with wood-glue. Once the glue is applied, the enclosure shells folds together along the V-grooves, capturing dividers in the dado grooves and secondary wraps, and evenly spreading the glue throughout the joints. One line of mechanical fasteners is applied to hold the structure together while the wood glue dries.

The V-groove technique greatly improves assembly efficiency, and also results in a far stronger and better sealed enclosure than the typical butt-joint construction found on imported enclosures. The quality of the MDF used in JL Audio systems is also vastly better than the typical "China-Grade MDF" used in the imported products.

Dynamic Motor Analysis - DMA Optimized Motor - JL Audio's proprietary Dynamic Motor Analysis system is a powerful suite of FEA-based modeling systems, first developed by JL Audio in 1997 and refined over the years to scientifically address the issue of speaker motor linearity. This leads to vastly reduced distortion and faithfully reproduced transients... or put simply: tight, clean, articulate bass.

Since 1997, JL Audio has been at the forefront of Finite Element Analysis-based modeling of loudspeaker motors and suspensions. This research is aimed at decoding what we refer to as the "Loudspeaker Genome"... a project aimed at understanding the true behavior of loudspeakers under power and in motion. A major component of this integrated system is DMA (Dynamic Motor Analysis). Starting with the 15W3v3 and the W7 Subwoofers in the late 1990's and early 2000's, DMA has played an important role in the design of all JL Audio woofers sold today, including their component woofers.

DMA is a Finite Element Analysis (FEA)-based system, meaning that it takes a large, complex problem, breaks it down into small solution elements for analysis and then assembles the data to form an accurate, "big-picture" solution. DMA's breakthrough is that it actually considers the effects of power through the coil as well as coil/cone position within the framework of a time-domain analysis. This gives us a highly accurate model of a speaker's actual behavior under real power, something that the traditional Thiele-Small models or other low power measurements cannot do. Because DMA does not rely on a steady-state model, it is able to consider shifts in the circuit elements being analyzed. These modeling routines are intense, requiring hours to run for a whole speaker.

DMA is able to analyze the real effects of fluctuating power and excursion upon the magnetic circuit of the motor, specifically the dynamic variations of the "fixed" magnetic field. This delivers intensely valuable information compared to traditional modeling, which assumes that the "fixed" field produced in the air gap by the magnet and the motor plates is unchanging. DMA not only shows that this "fixed" field changes in reaction to the magnetic field created by current flowing through the voice coil, but it helps JL Audio's engineers arrive at motor solutions that minimize this instability. Analyzing this behavior is critical to understanding the distortion mechanisms of a speaker motor and sheds light on the aspects of motor design that determine truly linear behavior:

• 1. Linear motor force over the speaker's operational excursion range
• 2. Consistent motor force with both positive and negative current through the coil
• 3. Consistent motor force at varying applied power levels

JL Audio's ability to fully analyze these aspects of motor behavior allows their transducer engineers to make critical adjustments to motor designs that result in extremely linear, highly stable dynamic loudspeaker motor systems.

The payoff is reduced distortion, improved transient performance and stellar sound quality.

Elevated Frame Cooling (U.S. Patent #6,219,431 & #6,229,902) - JL Audio's patented Elevated Frame Cooling design delivers cool air through slots directly above the top-plate to the voice coil of the speaker. This not only enhances power handling, but also sound quality by minimizing dynamic parameter shifts and power compression.

Many speakers employ venting techniques to enhance voice coil cooling. This is typically accomplished by having big holes in the sides of the frame just below the spider attachment shelf. While it provides a modest cooling benefit, this low-velocity air-flow does not blow directly or strongly on the voice coil.

JL Audio's patented design improves upon this cooling technique in a number of ways. By elevating the frame above the top-plate of the motor (via stand-offs integrated into the bottom of the frame) a narrow, high-velocity air-path is created between the bottom surface of the frame and the top surface of the top-plate. This air path leads directly to the voice coil and then turns upward into the spider air cavity. By utilizing the pumping action of the spider through this focused air path, a large volume of cool air hits the coil windings directly.

Another important benefit is that the upper surface of the top-plate (one of the speaker's hottest parts) is directly exposed to cooling air flow, whereas on a conventional design it is isolated from the air flow by the lower flange of the frame. The elevated frame technology greatly increases thermal power handling, reduces compression effects and does so without any additional parts.

JL Audio - Ahead of the curve.

Features and Specifications:

• Powered Subwoofer System with Single 10WXv2-4 Subwoofer Driver, Dark Gray Carpet (175 W, 4 Ohm) - Sealed Enclosure
• Continuous Power Handling (RMS) - Built-In Amplifier 175 W @ 4 Ohm
• System Nominal Impedance - 4 Ohm
• Enclosure Type - Sealed, Rear-Firing Design
• Finish - Gray Carpet, Mounted Amplifier With Shroud
• Grille Included - No
• UPC 0699440932486
• Color: Dark Gray
• Manufacturer's Limited Warranty - 2 Year(s)
• Sold: Each
