FireStik (SS-204A) - Stainless Steel Adjustable Vertical Door Jamb Mount, with SO-239 Base Antenna Stud Mount, Mobile Antenna Mounts


Product ID:   PID0246
Status: Available To Order


FireStik (SS-204A) - Stainless Steel Adjustable Vertical Door Jamb Mount, with SO-239 Base Antenna Stud Mount, Mobile Antenna Mounts



Price:
Quantity:









FireStik (SS-204A) - Stainless Steel Adjustable Vertical Door Jamb Mount, with SO-239 Base Antenna Stud Mount


Description:

These mounts were specifically designed to allow antenna installations on vehicles where other mounts may not work. The primary goal was to offer a mount that could be affixed to a vertical inner door jamb such as that which might be found on the rear or side door of a cargo type van. Since the mounting screws are meant to be on the inner edge of the jamb, visible holes in the vehicle body are eliminated. Like many other FireStik mounts, the versatility of these mounts go well beyond their targeted use. When you hold this mount in your hand you will start to recognize all of the mounting possibilities. Chances are, you will find several locations to mount it on your vehicle. For antennas up to 4ft in length.

In order to give you many years of trouble free use, the bracket parts and mounting hardware are made of stainless steel. The bracket is 1.5" (38mm) wide and has a 2" (50mm) reach for mounting inside the door jamb. Overall, the mount is 4.2" (105mm) long. In order to compensate for the door jamb angles, the stud bracket will swivel a full 180 degrees, 90 in each direction. This adjustment feature will let you mount the antenna on either the left or right side of the vehicle.

The SS-204A includes the K-4A, SO-239 base antenna stud mount. If the mounting situation allows for the required space to use a screw on coax connector (PL-259) on the mount end of the coax, this is the mount to choose.

May be used with any 3/8"-24 threaded antenna or accessory.


FireStik Antenna Company - Manufacturer of FireStik brand CB Antennas, Safety Flags and accessories.


Features and Specifications:

  • Adjustable Vertical Door Jamb Mount
  • Stainless Steel
  • Can Be Affixed to a Vertical Inner Door Jam
  • The Versatility of This Mount Goes Well Beyond Its Targeted Use
  • For Use with Antennas Up To 4ft In Length
  • The Stud Bracket Will Swivel a Full 180 Degrees, 90 In Each Direction
  • Mount the Antenna on Either the Left or Right Side of the Vehicle
  • SO-239 Base Antenna Stud Mount - For Coaxial Cable with a PL-259 Connector
  • Standard 3/8"-24 Threads
  • UPC 0716414201093
  • Manufacturer's Limited Warranty - 2 Year(s)
  • Sold: Each


FireStik (SS-204A) - Stainless Steel Adjustable Vertical Door Jamb Mount

Please Note:
  • This Selection Is FireStik (SS-204A) ONLY.
  • Manufacturer's product specifications, packaging and limited warranties (if applicable) are subject to change.
  • Images are solely for illustrative purposes and may reflect multiple items or multiple views of a single item.
  • This Item Is Sold: Each





Inventory Status: Available To Order
