Connex (CX-4600TURBO) - AM/FM/PA, Black, 10 Meter Amateur Mobile Radios


Product ID:   PID1631
Status: Out of Stock - do not order this product at this time


Connex (CX-4600TURBO)  - AM/FM/PA,  Black, 10 Meter Amateur Mobile Radios



Price:
Quantity:





"Optimum Performance" Upgrade Option:





Connex (CX-4600TURBO) - AM/FM/PA, Black


Description:

The Connex CX-4600TURBO features 150+ watt power output, blue lighting, front mic jack, echo with dual controls and switchable talkback.

Connex - Amateur and CB Radios


Features and Specifications:

  • 10 Meter Mobile Amateur Radio
  • AM/FM/PA
  • 150+ Watts
  • Small Meter with Scales for Signal Strength and Power Output
  • Front Panel 4 Pin Mic Jack
  • Blue Channel LED's
  • Rear Frequency Counter Jack
  • Vol, Sql, Mic Gain, RF Gain
  • Dual Echo and Talk Back with On/Off Switch
  • Band Selector (6 Bands)
  • Variable Power Control
  • ANL-NB or OFF Switch
  • +10 KHz On/Off Switch
  • Blue Lighting for Meter
  • RX/TX Indicator LED
  • Specifications:
    • General:
      • Model: CX-4600TURBO
      • Frequency Range: 28.015 to 28.585 MHz
      • Emission: AM/FM
      • Frequency Control: Phase-Lock-Loop (PLL) Synthesizer
      • Frequency Stability: 0.001%
      • Temperature Range: 0C to +50C
      • Antenna Impedance: 50 Ohms
      • Antenna Connectors: Standard SO-239 type
      • Input Voltage: 13.8V DC
      • Size: 2-3/8" (H) x 7-7/8" (W) x 10-3/4" (D)
      • Weight: 5 lb.
      • Meter: Illuminated; indicates relative output power, received signal strength
    • Transmitter:
      • RF Power Output: 50W
      • Spurious Emission: -50 dB
      • Audio Distortion: 10%
      • Frequency Response: 300 to 2500 Hz
      • Microphone: Plug-in dynamic; with push-to-talk switch and coiled cord
    • Receiver:
      • Sensitivity for 10 dB (S+N)/N: AM: 0.5 uV
      • Sensitivity for 12 dB (S+N)/N: FM: 0.25 uV
      • Squelch Sensitivity: 0.5 uV
      • Selectivity: -50 dB
      • Image Rejection: -50 dB
      • Hum & Noise: 40 dB
      • Audio Power Output: 2.5W @ 10% THD
  • Contents:
    • 10 Meter Connex CX-4600TURBO Radio
    • 4 Pin Stock Microphone
    • DC Power Cord
    • Mounting Bracket with Hardware
    • Microphone Hanger with Hardware
    • User's Manual
  • Color: Black
  • Manufacturer's Limited Warranty - 1 Year(s)
  • Sold: Each


Connex (CX-4600TURBO) - 10 Meter Amateur Radio
Connex (CX-4600TURBO) - 10 Meter Amateur Radio


Connex (CX-4600TURBO) - Operation's Guide
Connex (CX-4600TURBO) - Operation's Guide


The CX-4600TURBO Manual


Connex (CX-4600TURBO) - AM/FM/PA

Please Note:
  • This Selection Is Connex (CX-4600TURBO) ONLY.
  • Manufacturer's product specifications, packaging and limited warranties (if applicable) are subject to change.
  • Images are solely for illustrative purposes and may reflect multiple items or multiple views of a single item.
  • This Item Is Sold: Each




Inventory Status: Out of Stock - do not order this product at this time
